Card-Lok Series 223


  모델명 : Series 223


CATALOG
장비사양

Series 223

Catalog Number:223



  • For cold wall applications
  • Screw actuated, torque limiting
  • 5 segment, non-shafted design
  • Profile 5.72 mm (.225 in) x 6.86 mm (.270 in)
  • Min expansion 8.26 mm (.325 in)
  • Lengths 96.5 mm (3.8 in) to 325 mm (12.8 in), 12.7 mm (0.5 in) increments
  • Weight 1.12 g/cm (.100 oz/in)
  • Flexible mounting options
  • Available with gold chem film, clear chem film, black anodized, hard black anodized, or electroless nickel plating
  • Clamp force, thermal transfer, life cycle and environmental (MIL 810) test results available
  • Each unit tested at factory prior to shipment to ensure performance; customer provided with a certificate of conformance
